SHY201 Ex PTZ

Model: SHY201

Name: Ex PTZ

Ex Mark: ExdⅡCT6/DIP A20 TA,T6

IP Level: IP68

Description:

SHY201 Explosion-proof Pan/tilt is designed for use in explosive atmosphere such as gas group ⅡC (typical gas vapours: hydrogen, acetylene, ethene, coke-oven gas and methyl ether etc.) as well as flammable dust.

It is designed according to National standard and is built to IP68 protection level requirement.

The pan/tilt has a huge load capacity, smooth rotation, smaller noise and high reliability.

Its built-in decoder controls its rotation, camera lens and wiper.

With highest compound explosion-proof certification, it has proper configuration, light weight as well as easy installation and maintenance, providing best safety control.

Model	SHY201
Certification Parameter
Manufacturers Standard	GB3836-2000, GB12476.1-2000
Configuration Mode	Explosion-proof spigot joints
Explosion-proof Mark	ExdⅡCT6 / DIP A20 TA,T6
IP	IP68
Operating Temperature	-25°～60℃_注_note
Relative Humidity	≤95% (+25℃)
Cable Entries	2×G1/2”Explosion-proof cable entries , Dia. of inner hole Φ12
Mechanical Features
Material	Carbon steel / Stainless steel (304/316L)
Pan/Tilt Range	360° / ±60°
Pan/Tilt Rotate Speed	10 °/s
Pan/Tilt Driving Torque	20 N. m / 30 N. m
Gear Clearance	±0.3°
Electric Motor	The permanent magnetism DC motor of high torque matches the planetary gear reducer of high precision
Transmission Structure	All-gear structure
Outside Dimensions	210×165×345
Weight	11 Kg
Built-in Decoder With ZOOM Control
Communication Interface	RS-485 semiduplex
Communication Protocol	PELCO-D (other protocols replaced according to consumer’s demands)
Baud Rate	1200 / 2400 / 4800 / 9600 / 19200
Power Supply
Voltage	220V AC
Current	0.5 A
Others
Optional	Heater
